怎么繪制液壓系統圖和編制技術文件？

今天咋們來聊一聊液壓系統圖到底是怎么繪制的，還有技術文件的編制。

一、繪制工作圖

(1)液壓系統原理圖 圖上除畫出整個系統的回路之外，還應注明各元件的規格、型號、壓力調整值，并給出各執行元件的工作循環圖，列出電磁鐵及壓力繼電器的動作順序表。
(2)集成油路裝配圖 若選用油路闆，應將各元件畫在油路闆上，便于裝配;若采用集成塊或疊加閥時，因有通用件，設計者隻需選用，最后將選用的産品組合起來給制成裝配圖。

(3)泵站裝配圖 將集成油路裝置、泵、電動機與油箱組合在一起畫成裝配圖，表明它們各自之間的相互位置、安裝尺寸及總體外形。
(4)畫出非標準專用件的裝配圖及零件圖。

(5)管路裝配圖 表示出油管的走向，注明管道的直徑及長度，各種管接頭的規格、管夾的安裝位置和裝配技術要求等。
(6)電氣線路圖 表示出電動機的控制線路，電磁閥的控制線路、壓力繼電器和行程開關等。

二、編寫技術文件
技術文件一般包括液壓系統設計計算說明書，液壓系統的使用及維護技術說明書，零部件目錄表、標準件通用件及外購件總表等。
